TP-LINK 16-Port 10/100/1000Mbps Gigabit Ethernet Workgroup Switch Item # 259393 OfficeMax # 23626649

TP-LINK 16-Port 10/100/1000Mbps Gigabit Ethernet Workgroup Switch

5.0 Stars 5 1 5 1 Reviews

Description

Improve your network speed

  • High-speed Gigabit Ethernet switch features 16 ports with connection speeds up to 1000Mbps.  Helps ensure graphics, CGI, CAD or multimedia files and other applications are transferred rapidly across your network.
  • Nonblocking switching architecture greatly improves network response times.
  • Compatible with most 10, 100 and 1000Mbps Ethernet devices.
  • Diagnostic LED indicators on the front panel display power, link/activity and speed information.
  • Supports Mac address auto-learning and auto-aging.
  • Energy-efficient technology conserves up to 40% power.  Automatically powers down ports idle ports and budgets power output for different Ethernet cable lengths.
  • Plug-and-play design simplifies the installation process.  Auto cable connection on all ports eliminates the need for crossover cables and uplink ports.
  • Includes rack-mounting kit for seamless integration of the switch into your existing setup.

Back to Menu

Product Details

Item # 259393
Manufacturer # 3298573
Ethernet Technology Gigabit Ethernet; Fast Ethernet
plug and play yes
power source Power Supply
maximum data transfer rate 1,000 Mbps
cable included yes
Total Number of Network Ports 16
height 1.7 in
Number of Network (RJ-45) Ports 16
width 11.6 in
depth 7.1 in
Product Name TL-SG1016D 16-Port Gigabit Desktop Switch
manufacturer TP-LINK
brand name TP-LINK
Input Voltage 110 V AC; 220 V AC
Port/Expansion Slot Details 16 x Gigabit Ethernet Network
Layer Supported 2
ports 16
form factor Rack-mountable; Desktop
warranty length 5-year limited
model name TL-SG1016D
internal/external external
Network Technology 10/100/1000Base-T

Back to Menu

Back to Menu

Back To Top

From the Manufacturer|Powered by Webcollage

Thank You Is the information in this section helpful? Yes / No

Overview

  • What This Product Does

    Improve the speed of your office and workgroup network with the TP-LINK TL-SG1016D 16-Port Gigabit Desktop/Rackmount Switch. It has 16 ports offering connection speeds of up to 1,000 Mbps for your network, perfect for ensuring that graphics, CGI, CAD, or multimedia files and other applications with bandwidth-intensive files are transferred across the network almost instantly. Plus, with the innovative energy-efficient technology, the TL-SG1016D can save up to 40% of the power consumption, making it an eco-friendly solution for your business network.

  • Plug-and-Play Simplicity

    The TL-SG1016D requires no configuration and can simply be plugged in and used. Auto MDI/MDI-X cable detection on all ports eliminates the need for crossover cable or uplink ports. Each port can be directly connected to a server, hub, router, or switch using a straight or crossover cable, so there's no confusion about port specificity.

  • Faster Network Response Times

    With non-blocking switching architecture, the TL-SG1016D greatly improves network response times and significantly speeds up the traffic between subnets by forwarding and filtering packets at full wire speed for maximum throughput.

  • Go Green With Your Ethernet

    The TL-SG1016D includes green Ethernet technology and power-saving features to help make your network compatible without compromising performance. The switch automatically powers down the ports that are idle and budgets power output for different Ethernet cable lengths.

  • Universal System Compatibility

    Compatible with all 10, 100, and 1,000 Mbps Ethernet devices, the TL-SG1016D allows you to protect your existing investments while migrating to a faster network. All ports support full- and half-duplex transfer modes for 10/100 Mbps and full-duplex transfer mode for 1,000 Mbps. The TL-SG1016D also supports IEEE 802.3x flow control for full-duplex mode and backpressure for half-duplex transfer mode.

  • Diagnostic LED Indicators

    Diagnostic LEDs on the front panel display information for power, link/activity, and speed, enabling you to quickly detect and correct problems on the network.
See More:

Warranty

  • Need assistance setting up your TP-LINK device? Our team is here 24/7 to provide toll-free technical support. Whether you bought a TP-LINK product yesterday or years ago, we can help with product setup and configuration at no extra charge. Plus, our 5-year warranty grants you worry-free service for peace of mind

Product Views

{"images":[{"assetWrapper":"image-gallery","runtimeSrc":{"height":500,"width":1280,"src":"/_cp/products/1321846462513/tab-abfeb15d-6335-4672-8d60-03a72c9ae0ff/a8b0fdea-b0b8-4dcb-81d7-2ba5c5ff6f5d.jpg.web.jpg"},"isAdaCompliant":false,"src":{"height":500,"width":1280,"src":"/_cp/products/1321846462513/tab-abfeb15d-6335-4672-8d60-03a72c9ae0ff/a8b0fdea-b0b8-4dcb-81d7-2ba5c5ff6f5d.jpg"},"sources":[{"height":375,"width":960,"src":"/_cp/products/1321846462513/tab-abfeb15d-6335-4672-8d60-03a72c9ae0ff/a8b0fdea-b0b8-4dcb-81d7-2ba5c5ff6f5d.jpg.w960.jpg","profile":"W960"},{"height":187,"width":480,"src":"/_cp/products/1321846462513/tab-abfeb15d-6335-4672-8d60-03a72c9ae0ff/a8b0fdea-b0b8-4dcb-81d7-2ba5c5ff6f5d.jpg.w480.jpg","profile":"W480"},{"height":93,"width":240,"src":"/_cp/products/1321846462513/tab-abfeb15d-6335-4672-8d60-03a72c9ae0ff/a8b0fdea-b0b8-4dcb-81d7-2ba5c5ff6f5d.jpg.w240.jpg","profile":"W240"}]},{"assetWrapper":"image-gallery","runtimeSrc":{"height":540,"width":1280,"src":"/_cp/products/1321846462513/tab-abfeb15d-6335-4672-8d60-03a72c9ae0ff/a8586bd4-0c55-4e01-bc6a-baebe60235b0.jpg.web.jpg"},"isAdaCompliant":false,"src":{"height":540,"width":1280,"src":"/_cp/products/1321846462513/tab-abfeb15d-6335-4672-8d60-03a72c9ae0ff/a8586bd4-0c55-4e01-bc6a-baebe60235b0.jpg"},"sources":[{"height":405,"width":960,"src":"/_cp/products/1321846462513/tab-abfeb15d-6335-4672-8d60-03a72c9ae0ff/a8586bd4-0c55-4e01-bc6a-baebe60235b0.jpg.w960.jpg","profile":"W960"},{"height":202,"width":480,"src":"/_cp/products/1321846462513/tab-abfeb15d-6335-4672-8d60-03a72c9ae0ff/a8586bd4-0c55-4e01-bc6a-baebe60235b0.jpg.w480.jpg","profile":"W480"},{"height":101,"width":240,"src":"/_cp/products/1321846462513/tab-abfeb15d-6335-4672-8d60-03a72c9ae0ff/a8586bd4-0c55-4e01-bc6a-baebe60235b0.jpg.w240.jpg","profile":"W240"}]},{"assetWrapper":"image-gallery","runtimeSrc":{"height":853,"width":1280,"src":"/_cp/products/1321846462513/tab-abfeb15d-6335-4672-8d60-03a72c9ae0ff/9b48078f-536c-403c-8c45-ab214b5c52a0.jpg.web.jpg"},"isAdaCompliant":false,"src":{"height":853,"width":1280,"src":"/_cp/products/1321846462513/tab-abfeb15d-6335-4672-8d60-03a72c9ae0ff/9b48078f-536c-403c-8c45-ab214b5c52a0.jpg"},"sources":[{"height":639,"width":960,"src":"/_cp/products/1321846462513/tab-abfeb15d-6335-4672-8d60-03a72c9ae0ff/9b48078f-536c-403c-8c45-ab214b5c52a0.jpg.w960.jpg","profile":"W960"},{"height":319,"width":480,"src":"/_cp/products/1321846462513/tab-abfeb15d-6335-4672-8d60-03a72c9ae0ff/9b48078f-536c-403c-8c45-ab214b5c52a0.jpg.w480.jpg","profile":"W480"},{"height":159,"width":240,"src":"/_cp/products/1321846462513/tab-abfeb15d-6335-4672-8d60-03a72c9ae0ff/9b48078f-536c-403c-8c45-ab214b5c52a0.jpg.w240.jpg","profile":"W240"}]}]}

Features

  • Innovative energy-efficient technology saves power up to 40%
  • Supports IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode
  • Non-blocking switching architecture that forwards and filters packets at full wire-speed for maximum throughput
  • 32Gbps Switching Capacity
  • 10K Jumbo frame improves performance of large data transfers
  • Auto-MDI/MDIX eliminates the need for crossover cables
  • Supports MAC address auto-learning and auto-aging
  • Store and forward Switching scheme
  • Auto-negotiation ports provide smart integration between 10Mbps, 100Mbps and 1000Mbps hardware.
  • Plug and Play design simplifies installation

Package Content

  • 16-Port Gigabit Switch
  • Rackmount Kit
  • Power Cord
  • User Guide
